Intel S2600CP User Manual

Hardware Installations and Upgrades
102 Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide
Figure 124. Memory RAS and Performance Configuration Screen
Advanced
Memory RAS and Performance Configuration
Capabilities
Screen Field Descriptions:
Memory Mirroring Possible
Yes/No
Memory Rank Sparing Possible Yes/No
Memory Lockstep Possible Yes/No
Select Memory RAS Configuration
Maximum Performance/Mirroring/Rank
Sparing/Lockstep
NUMA Optimized Enabled/Disabled
Screen Field Descriptions:
1. Memory Mirroring Possible
Option Values: Yes
No
Help Text: <None>
Comments: Information only
. Displays whether the current DIMM configuration is
capable of Memory Mirroring. For Memory Mirroring to be possible, DIMM configurations on
all paired channels must be identical between the channel pair (Mirroring Domain).
Back to [Memory RAS and Performance Configuration Screen] — [Memory Configuration
Screen] — [Advanced Screen]
2. Memory Rank Sparing Possible
Option Values: Yes
No
Help Text: <None>
