Hardware Installations and Upgrades
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 117
21. NIC1 Port1 MAC Address
22. NIC1 Port2 MAC Address
23. NIC1 Port3 MAC Address
24. NIC1 Port4 MAC Address
25. NIC2 Port1 MAC Address
26. NIC2 Port2 MAC Address
27. NIC2 Port3 MAC Address
28. NIC2 Port4 MAC Address
Option Values: <Mac #>
Help Text: <None>
Comments: Information only
. 12 hex digits of the MAC address of Onboard Network
Controller <n = 1-2> Port <x = 1-4>.
This option will not appear when NIC<n> is disabled or when NIC<n> Port<x> is disabled.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
Serial Port Configuration
The Serial Port Configuration screen allows the user to configure the Serial A [COM 1] and Serial B
[COM2] ports.
To access this screen from the Main screen, select Advanced > Serial Port Configuration. To move to
another screen, press the <Esc> key to return to the Advanced screen, then select the desired screen.

Intel S2600CP Specifications

General

Processor Support	Intel Xeon processor E5-2600 product family
Chipset	Intel C602
Memory Slots	24 DIMM slots
Form Factor	SSI EEB (12" x 13")
Storage	Up to 8 SATA/SAS drives
Network	Dual Gigabit Ethernet
CPU Socket Type	LGA 2011
SATA	SATA II and SATA III
RAID Support	RAID 0, 1, 5, 10
Network Controller	Intel 82574L
Power Supply	Redundant power supply support
Management	IPMI 2.0
