Hardware Installations and Upgrades
116 Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide
12. NIC1 Port1 PXE
13. NIC1 Port2 PXE
14. NIC1 Port3 PXE
15. NIC1 Port4 PXE
16. NIC2 Port1 PXE
17. NIC2 Port2 PXE
18. NIC2 Port3 PXE
19. NIC2 Port4 PXE
Option Values: Enabled
Disabled
Help Text:
Enable/Disable Onboard NIC<n> Port<x> LOM PXE Boot
Comments: This will enable or disable PXE Boot capability for Port <x = 1-4> of
Onboard Network Controller <n = 1-2>. The NIC<n> Port<x> PXE option and MAC Address
display will not appear when this option is disabled.
This option will not appear when NIC<n> is disabled or when NIC<n> Port<x> is disabled.
In order to disable the PXE Boot OPROM for NIC1 (1Gb) or NIC2 (10Gb), PXE Boot must be
disabled for all ports on the corresponding NIC1 or NIC2.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
20. Onboard NIC iSCSI
Option Values: Enabled
Disabled
Help Text:
Enable/Disable Onboard NIC iSCSI Option ROM Load.
Comments: This option is grayed out and not accessible if either the NIC1 or NIC2
ROMs are enabled. There is one iSCSI Option ROM for all onboard NICs/Ports.
If both of the onboard NIC are enabled and
the iSCSI Option ROM is disabled, the onboard NICs
cannot be booted and cannot Wake-on-LAN.
This option does not appear on some models.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
