Hardware Installations and Upgrades
110 Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide
Comments: Information only. If no Storage module is detected, then None is
displayed. This shows the customer the product name of the module installed, which helps in
identifying drivers, support, documentation, etc.
Back to [Mass Storage Controller Configuration Screen]
9. SATA Port
(For Port numbers 0-1)
Option Values: Not Installed
<Drive Information>
Help Text: <None>
Comments: Information only
. The Drive Information, when present, will typically
consist of the drive model identification and size for the disk drive installed on a particular port.
This Drive Information line is repeated for all 2 SATA Porst for the onboard AHCI capable
SATA Controller. However, for any given board, only the ports which are physically populated
on the board are shown. That is, a board which only implements the two 6 GB/s ports 0 and 1 will
only show those two ports in this Drive Information list.
This section for Drive Information does not appear at all when the SCU is set to Disabled or the
SATA operational mode is RAID Mode, nor for any drives attached to the SCU SATA or SAS
ports. In these cases the BBS information is not available to display.
Back to [Mass Storage Controller Configuration Screen]
PCI Configuration
The PCI Configuration screen allows the user to configure the PCI memory space used for onboard and
add-in adapters, configure video options, and configure onboard adapter options.
It also includes a selection option to go to the NIC Configuration screen.
