Intel S2600CP User Manual

Hardware Installations and Upgrades
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 113
5. NIC Configuration Screen
Option Values: <None>
Help Text:
View/Configure PCI information and settings.
Comments: Selection only
. Position to this line and press the <Enter> key to go to the
NIC Configuration group of configuration settings.
Back to [PCI Configuration Screen] — [Advanced Screen]
NIC Configuration
The NIC Configuration screen allows the user to configure the NIC adapter options. It also displays the
NIC MAC Addresses currently in use.
To access this screen from the Main screen, select Advanced > PCI Configuration > NIC Configuration.
To move to another screen, press the <Esc> key to return to the PCI Configuration screen, if necessary
press the <Esc> key again to return to the Advanced screen, then select the desired screen.

Intel S2600CP Specifications

General

Processor Support	Intel Xeon processor E5-2600 product family
Chipset	Intel C602
Memory Slots	24 DIMM slots
Form Factor	SSI EEB (12" x 13")
Storage	Up to 8 SATA/SAS drives
Network	Dual Gigabit Ethernet
CPU Socket Type	LGA 2011
SATA	SATA II and SATA III
RAID Support	RAID 0, 1, 5, 10
Network Controller	Intel 82574L
Power Supply	Redundant power supply support
Management	IPMI 2.0
