Server System Features
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide 11
A Reserved
B Power Connector
C Mini-SAS Connectors
D I
2
C In Connector
Figure 12. 8x3.5 backplane – Rear View
8 x 2.5-inch Hard Drive Backplane
A SAS/SATA Hot-swap Connectors
Figure 13. 8 x 2.5 backplane - Front View
