Intel S2600CP User Manual

Hardware Installations and Upgrades
78 Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide
Main Screen (Tab)
The Main Screen is the first screen that appears when the BIOS Setup configuration utility is entered,
unless an error has occurred. If an error has occurred, the Error Manager Screen appears instead.
Figure 120. Main Screen
Main Advanced Security Server Management Boot Options Boot Manager
Logged in as:
Administrator/User
Platform ID <Platform Identification String>
System BIOS
BIOS Version <Platform.86B.xx.yy.zzzz>
Build Date <MM/DD/YYYY>
Memory
Total Memory <Amount of memory installed>
Quiet Boot Enabled/Disabled
POST Error Pause Enabled/Disabled
System Date [Day MM/DD/YYYY]
System Time [HH:MM:SS]
Screen Field Descriptions
:
1. Logged in as:
Option Values: <Administrator / User>
Help Text: <None>
Comments: Information only
. Displays password level that setup is running in:
Administrator or User. With no passwords set, Administrator is the default mode.
Back to [Main Screen]

Intel S2600CP Specifications

General

Processor Support	Intel Xeon processor E5-2600 product family
Chipset	Intel C602
Memory Slots	24 DIMM slots
Form Factor	SSI EEB (12" x 13")
Storage	Up to 8 SATA/SAS drives
Network	Dual Gigabit Ethernet
CPU Socket Type	LGA 2011
SATA	SATA II and SATA III
RAID Support	RAID 0, 1, 5, 10
Network Controller	Intel 82574L
Power Supply	Redundant power supply support
Management	IPMI 2.0
