Intel S2600CP User Manual

Hardware Installations and Upgrades
114 Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide
Figure 127. NIC Configuration Screen
Advanced
NIC Configuration
Wake on LAN (PME) Enabled / Disabled
Onboard NIC1 Enabled / Disabled
NIC1 Port1 Enabled / Disabled
NIC1 Port2 Enabled / Disabled
NIC1 Port3 Enabled / Disabled
NIC1 Port4 Enabled / Disabled
NIC1 Port1 PXE Enabled / Disabled
NIC1 Port2 PXE Enabled / Disabled
NIC1 Port3 PXE Enabled / Disabled
NIC1 Port4 PXE Enabled / Disabled
Onboard NIC iSCSI Enabled / Disabled
NIC1 Port1 MAC Address <MAC #>
NIC1 Port2 MAC Address <MAC #>
NIC1 Port3 MAC Address <MAC #>
NIC1 Port4 MAC Address <MAC #>
Screen Field Descriptions
:
1. Wake on LAN (PME)
Option Values: Enabled
Disabled
Help Text:
Enables or disables PCI PME function for Wake on LAN capability from LAN adapters.
Comments: Enables/disables PCI/PCIe PME# signal to generate Power Management
Events (PME) and ACPI Table entries required for Wake on LAN (WOL). However, note that
this will enable WOL only with an ACPI-capable Operating System which has the WOL function
enabled.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
