7. RSTe Boot Configuration
Option Values: None
AHCI Capable Ctrlr
SAS/SATA Capable Ctrlr
Help Text:
This selects the device that will support Bootable Drives, whether they are in RAID
arrays or individual pass-through SAS/SATA drives. Once selected and set up (if
necessary), individual bootable devices will be listed in the Bootable Devices menu
display.
Comments: This option appears only when Intel
®
RSTe has been selected as the
operational mode on both the AHCI and SCU controllers. In that case there is a conflict and only
one controller can be selected as having bootable drives attached.
Once selected and set up (if necessary), individual bootable logical or physical drives available on
the selected controller will be listed in the Bootable Devices menu display.
If only one device selects RSTe, it will be available as a boot device along with any other devices
– this option is only necessary to distinguish between which RSTe device runs the OpROM
instance.
BIOS is required to designate the OpROM for the boot device selected here. Two iterations of the
OpROM cannot FULLY load simultaneously, and the version fully loaded will only show devices
connected to the given controller, so OpROM load order is based on BIOS selecting the correct
device.
/
NOTE
If RSTe is selected, then only one CONTROLLER can be bootable, so there will be situations
where the boot drive *OR* an optical device will be bootable, but not both.
Please also see the product System Guide for restrictions on expander boot support.
Back to [Mass Storage Controller Configuration Screen]
8. Intel
®
Storage Module
Option Values: None
<Name of Storage Module detected>
Names of Storage Modules supported at this time are
:
Intel
®
Integrated RAID Module
Intel
®
Integrated RAID Module RMS25PB040
Intel
®
Integrated RAID Module RMT3PB080
Intel
®
Integrated RAID Module RMS25CB080
Intel
®
Integrated RAID Module RMS25CB040
Intel
®
Integrated RAID Module RMT3CB080
Intel
®
Integrated RAID Module RMS25JB080
Intel
®
Integrated RAID Module RMS25JB040
Intel
®
Integrated RAID Module RMS25KB080
Intel
®
Integrated RAID Module RMS25KB040
Help Text: <None>

Intel S2600CP Specifications

General

Processor Support	Intel Xeon processor E5-2600 product family
Chipset	Intel C602
Memory Slots	24 DIMM slots
Form Factor	SSI EEB (12" x 13")
Storage	Up to 8 SATA/SAS drives
Network	Dual Gigabit Ethernet
CPU Socket Type	LGA 2011
SATA	SATA II and SATA III
RAID Support	RAID 0, 1, 5, 10
Network Controller	Intel 82574L
Power Supply	Redundant power supply support
Management	IPMI 2.0
