Invacare®LiNX
Fig.3-71
1.InsertclampplateBintocutoutontrayA.
2.FixclampplateB,clampballCandupperclamp
plateDwithscrewsE.
3.
Fig.3-72
InsertremoteHfrombelowintotrayA.Makesure,
arrowIshowsintoreversedrivingdirection.
NucleusTrayMount
CAUTION!
RiskofInjuryandDamage
Remainingburrsandmissingendcapsafter
modicationsonrods,suchasshortenedrod,
canleadtoinjuryordamage.
–Deburrcutaftercuttingexcessivelength.
–Re-installendcapafterdeburring.
–Checkendcapfortighttting.
•1/8inchAllenkey
•5/32inchAllenkey
•3/16inchAllenkey
Fig.3-73
1.InsertclampplateBintocutoutontrayA.
2.FixclampplateB,clampballCandupperclamp
plateDwithscrewsE.
3.
Fig.3-74
InsertremoteJfrombelowintotrayA.Makesure,
arrowKshowsintoreversedrivingdirection.
4.
Fig.3-75
PullhitchmountGovernucleusandtightenwith
screwP.
NucleusOnlyMount
CAUTION!
RiskofInjuryandDamage
Remainingburrsandmissingendcapsafter
modicationsonrods,suchasshortenedrod,
canleadtoinjuryordamage.
–Deburrcutaftercuttingexcessivelength.
–Re-installendcapafterdeburring.
–Checkendcapfortighttting.
