4.
Fig.3-79
MountanglebracketFwithscrewsGtotrayA.
5.
Fig.3-80
FixadapterblockKtoanglebracketFwithscrewH
andwasherI.
NucleusTrayMount
CAUTION!
RiskofInjuryandDamage
Remainingburrsandmissingendcapsafter
modicationsonrods,suchasshortenedrod,
canleadtoinjuryordamage.
–Deburrcutaftercuttingexcessivelength.
–Re-installendcapafterdeburring.
–Checkendcapfortighttting.
•1/8inchAllenkey
•5/32inchAllenkey
•3/16inchAllenkey
1.
Fig.3-81
InsertremoteOintoclampN.Pullclampover
adapterblockKandxwithscrewsL.
2.
Fig.3-82
InsertclampplateBintocutoutontrayA.
3.FixclampplateB,clampballCandupperclamp
plateDwithscrewsE.
4.
Fig.3-83
MountanglebracketHwithscrewsItotrayA.
