ModifyingwheelchaircongurationwithiOStool
ChangingMotionName
1.
Fig.8-14
TaponeldMotionName.
2.UnlockBulkModebeforemodifyingname.
3.TaponBack.
SeatingFunction
Thisparametersetshowthejoystickoperatesamotion.
Thejoystickcancontrolthemotionasaswitchorasa
proportionalcontroller.Therearefourswitch-typemodes
andoneproportional-typemode.
1.FromHomescreenopendesiredseatingfunction.
a.
Fig.8-15
InputMode:Congurationofuserinputforthis
seatingfunction.
•Forward/Reverse:Movingjoystickforwardor
reversetocontrolmotion.
•Left/Right:Movingjoystickleftorrightto
controlmotion.
•FourQuadrant:Usingallfourjoystick
quadrantstocontrolmotions.
IfFourQuadrantisselected,allquadrant
parameterscanbeeditedindividually.
b.
Fig.8-16
Motion:Ifthejoystickisusedtocontrolamotion,
thenselectthemotionfromthelistofavailable
motions.
Ifthejoystickisnotusedtocontrolamotion,then
selectNoMotionfromthelist.
c.OperatingMode:
Switch-typeProportionaltype
Switched
Latched
Toggle
Toggle/latch
Proportional
