Jacobsen Eclipse 322 Repair Manual

5-16 4222983 Second Edition
CHASSIS
5
Disassembly and Assembly
See Figure 5-22.
Figure 5-22
1 Screw (4) 5 Brake Arm Weldment 8 Switch Arm 11 Spring
2 Brake Pedal Position Sensor 6 Spring Roll Pin (2) 9 Brake Pedal Switch 12 Spacer (4)
3 Brake Plate (2) 7 Pedal Grip 10 Screw (4) 13 Nut (4)
4 Bushing (2)
1
3
2
TN2415
4
5
6
8
4
9
1
10
3
11
12
13
7
