3-19
4 If stop entering a value, left-click the Close button.
The numeric value input screen will close without reflecting the set value to the operating
state.
Increasing or decreasing a numeric value
Procedures 1 On the numeric value input dialog, left-click the up-down control button
▲ or ▼ .
For example, when adjusting 123.0° to 123.4° for a bearing value, sequentially left-click
the software number keys as shown below.
▲ → ▲ → ▲ → ▲
Latitude input screen
Entering latitude
Procedures 1 On the latitude input screen, sequentially press numeric keys to enter
latitude (XX°XX．XXX').
For example, to enter 12°34.567', sequentially press numeric keys as follows.
1 → 2 → 3 → 4 → 5 → 6 → 7
※ A numeric input outside the input range is not accepted.
When left-clicking CLR button, the value is canceled.
2 To make change between north latitude and south latitude, use N
and S .
North latitude: Left-click the N button.
South latitude: Left-click the S button.
Enter Button
N button
S button
Input range
Numeric button
Clear button
Close button
To Next Page
