3-52
3
3.6 Display User Map
y
y y
Moving a mark or line (Move)
With regard to the created user map, a mark or line is moved individually.
Procedures 1 Open the Edit User Map menu by performing the following menu
operation.
U.Map
→ Edit User Map
The Edit User Map menu will appear.
2 Left-click the Move button.
The user map move mode is selected.
Move Map(SP) is displayed in the cursor mode located at the upper right of the radar
display.
3 Put the cursor on a mark or line, and left-click.
When a mark or line to be moved is selected, the cross cursor mark will appear.
4 Move the cross cursor mark to the destination, and left-click.
The selected mark or line is moved to the destination.
To move another mark or line, repeat procedures 3 and 4.
5 When finished with the correction of all items, left-click the Exit
button.
The cursor mode changes to the normal operation mode, terminating the user map move
mode.
(Example)
To Next Page
