3-53
Deleting a mark or line (Delete)
With regard to the created user map, a mark or line is deleted individually.
Procedures 1 Open the Edit User Map menu by performing the following menu
operation.
U.Map
→ Edit User Map
The Edit User Map menu will appear.
2 Left-click the Delete button.
The user map delete mode is selected.
Map Delete is displayed in the cursor mode located at the upper right of the radar
display.
3 Put the cursor on a mark or line, and left-click.
The entire selected mark or line is deleted.
To delete another mark or line, repeat procedures 3 and 4.
4 When finished with the correction of all items, left-click the Exit
button.
The cursor mode changes to the normal operation mode, terminating the user map delete
mode.
