4-18
4
4.1 Use of Navigation Tools
y
yyy
[III] Operating EBL and VRM Concurrently (EBL and VRM)
Procedures 1 Put the cursor on the intersection marker ( ○ or ● ), and left-click.
When the cursor is moved to it, EBL1 VRM1 or EBL2 VRM2 is shown at the
upper right of the cursor. The EBL and VRM become operable when left-clicking.
2 Move the cursor to the bearing / range to be set.
The EBL and VRM will move as the cursor moves.
3 Left-click.
The EBL and VRM will be fixed.
[IV] Operating Parallel Index Lines (PI)
To change the direction of parallel index lines
Procedures 1 Put the cursor on near the center of line, and left-click.
When the cursor is moved there, it will turn into " " and PI will be displayed at the
upper right of the cursor. The parallel index lines become operable when left-clicking.
2 Move the cursor to the direction to be set.
The parallel index lines will change the direction as the cursor moves.
3 Left-click.
The parallel index lines will be fixed.
To Next Page
