7-17
Acknowledge State : Setting of ALR sentence.
A:ACK : Add acknowledgement to ALR sentence.
V:UNACK : Add no acknowledgement (unrecognized) to ALR
sentence.
Setting the Alarm Buzzer (Sound Output Mode)
This function enables the control of alarm buzzer.
Procedures 1. Open the Serviceman Menu.
2. Perform the following menu open procedure to open the Alarm menu.
Installation Menu
→ Alarm
→ Sound Output Mode
3 Left-click the Sound Output Mode combo box.
4. Select the function to be used.
The item is switched.
On
Off1 The explanation is in the following.
Off2
Setting and Alarm Function
Alarm
Setting
Operation
Operation
Miss
CPA/
TCPA
New
Target
Lost NAV System Interswitch
On
①
Off1
① ②
Off2
① ② ① ②
① : Followed by Buzzer Volume menu setting.
② : Alarm Buzzer is turned off.
For how to setting Buzzer Volume menu, see Section “3.8.9 Adjust Sound Volume (Buzzer
Vo l u m e ) ” .
Note:
If Sound Output Mode is set to ②, when Buzzer Volume menu setting is disabled.
