Keithley 2001 User Manual

Front Panel Operation
3-76
F
igure 3-35
Operation model for asynchronous Trigger Link example #2
Idle
Bypass
A
Wait for
Trigger Link
Trigger
Trigger
C
No
Scanned
10
Channels
?
Yes
Scan
Channel
Performed
2
Scans
?
Wait for
Trigger Link
Trigger
D
Output
Trigger
Trigger
B
No
Yes
Bypass
F
Output
Trigger
Trigger 2001
to make
Measurement
and Output
Trigger
E
Trigger Trigger
Trigger 230
to source
next voltage level
and Output
Trigger
G
7001 2001
7001 230
7001
Press STEP
2001
230

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
