Sequence Event Register:
Bit B0  Not used.
Bit B1, Layer 1 (Lay1)  Set bit indicates that instrument operation is in arm layer 1 (PTR), or
that operation has exited from arm layer 1 NTR).
Bit B2, Layer 2 (Lay2)  Set bit indicates that instrument operation is in arm layer 2 (PTR), or
that operation has exited from arm layer 2 NTR).
Bits B3 through B15  Not used.
Programming example 10 OUTPUT 716; “:stat:meas?”
20 ENTER 716; A$
30 PRINT A$
40 END
Line 10 Queries the Measure Event Register.
Line 20 Addresses the Model 2001 to talk.
Line 30 Displays the decimal value that defines which bits in the register are set.
F
igure 4-26
A
rm Event Register
B15 - B2
B1 B0
(2 )
1
2
0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Event Bit Set
0 = Event Bit Cleared
Seq1
Event : Seq1 = Sequence 1
F
igure 4-27
Sequence Event Register
Lay2
B15 - B3 B2 B1 B0
(2 )
2
4
(2 )
1
2
0/1 0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Event Bit Set
0 = Event Bit Cleared
Event : Lay1 = Layer 1
Lay2 = Layer 2
Lay1

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
