Keithley 2001 User Manual

IEEE-488 Reference
4-174
Trigger Event Register:
Bit B0  Not used.
Bit B1, Sequence 1 (Seq1)  Set bit indicates that the instrument is in the trigger layer (PTR),
or that the instrument has exited from the trigger layer (NTR).
Bits B2 through B15  Not used.
Arm Event Register:
Bit B0  Not used.
Bit B1, Sequence 1 (Seq1)  Set bit indicates that the instrument is in an arm layer (PTR), or
that the instrument has exited from the arm layers (NTR).
Bits B2 through B15  Not used.
Idle Arm Trig
B15 - B11 B10
B9 B8 B7 B6 B5
B4 B3
B2 B1
B0
(2 )
10
1024
(2 )
9
(2 )
6
(2 )
5
(2 )
1
(2 )
0
64 32
0/1 0/1 0/1
0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Operation Event Set
0 = Operation Event Cleared
Events : Idle = Idle state of the 2001
Calc = Calculating
Arm = Waiting for Arm
Trig = Waiting for Trigger
Set = Settling
Cal = Calibrating
Set
2
Calc Cal
512 1
0/1 0/1
F
igure 4-24
Operation Event Register
F
igure 4-25
Trigger Event Register
B15 - B2
B1 B0
(2 )
1
2
0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Event Bit Set
0 = Event Bit Cleared
Event : Seq1 = Sequence 1
Seq1
