Keithley 2001

SCPI Command Subsystems
D-19
Table D-12
Trigger command summary
Command Description
:INITiate
[:IMMediate]
:CONTinuous <b>
:CONTinuous?
:ABORt
:ARM[:SEQuence[1]]
[:LAYer[1]]
:IMMediate
:COUNt <n>
:COUNt?
:SOURce <name>
:SOURce?
:SIGNal
:TCONfigure
:DIRection <name>
:DIRection?
:ASYNchronous
:ILINe <NRf>
:ILINe?
:OLINe <NRf>
:OLINe?
:LAYer2
:IMMediate
:COUNt <n>
:COUNt?
:DELay <n>
:DELay?
:SOURce <name>
:SOURce?
:TIMer <n>
:TIMer?
:SIGNal
:TCONfigure
:DIRection <name>
:DIRection?
:ASYNchornous
:ILINe <NRf>
:ILINe?
:OLINe <NRf>
:OLINe?
Subsystem command path:
Initiate one trigger cycle.
Enable (1 or ON) or disable (0 or OFF) continuous initiation of trigger system.
Query continuous initiation.
Reset trigger system.
Subsystem command path to configure arm layers:
Path to program arm layer 1:
Loop around control source.
Program arm count (1 to 99999, or INF).
Query arm count.
Select control source: HOLD, IMMediate, MANual, BUS, TLINk,
EXTernal.
Query control source.
Loop around control source.
Path to configure Triggers:
Enable (SOUR) or disable (ACC) Bypass: SOURce, ACCeptor.
Query direction.
Path to configure asynchronous Trigger Link:
Select input line (1 to 6).
Query input line.
Select output line (1 to 6).
Query output line.
Path to program arm layer 2:
Loop around control source.
Program scan count (1 to 99999 or INF).
Query scan count.
Program delay (0 to 999999.999 sec)
Query delay.
Select control source: HOLD, IMMediate, TIMer, MANual, BUS, TLINk,
EXTernal.
Query control source.
Set timer interval (0.001 to 999999.999 sec)
Query timer.
Loop around control source.
Path to configure Triggers:
Enable (SOUR) or disable (ACC) Bypass: SOURce, ACCeptor.
Query direction.
Path to configure asynchronous Trigger Link:
Select input line (1 to 6).
Query input line.
Select output line (1 to 6).
Query output line.
