Keithley 2001 User Manual

IEEE-488 Reference
4-221
4.24 Trigger subsystem
The Trigger subsystem is made up of a series of commands and subsystems to configure the
three layers of the Trigger Model (see Figure 4-13). These commands and subsystems are sum-
marized in Table 4-32.
Table 4-32
Trigger command summary
Command Description Reference
:INITiate
[:IMMediate]
:CONTinuous <b>
:CONTinuous?
:ABORt
:ARM[:SEQuence[1]]
[:LAYer[1]]
:IMMediate
:COUNt <n>
:COUNt?
:SOURce <name>
:SOURce?
:SIGNal
:TCONfigure
:DIRection <name>
:DIRection?
:ASYNchronous
:ILINe <NRf>
:ILINe?
:OLINe <NRf>
:OLINe?
:LAYer2
:IMMediate
:COUNt <n>
:COUNt?
:DELay <n>
:DELay?
:SOURce <name>
:SOURce?
:TIMer <n>
:TIMer?
:SIGNal
:TCONfigure
:DIRection <name>
:DIRection?
:ASYNchornous
:ILINe <NRf>
:ILINe?
:OLINe <NRf>
:OLINe?
Subsystem command path:
Initiate one trigger cycle.
Enable (1 or ON) or disable (0 or OFF) continuous initiation of trigger sys-
tem.
Query continuous initiation.
Reset trigger system.
Subsystem command path to configure arm layers:
Path to program arm layer 1:
Loop around control source.
Program arm count (1 to 99999, or INF).
Query arm count.
Select control source: HOLD, IMMediate, MANual, BUS, TLINk, EXTer-
nal.
Query control source.
Loop around control source.
Path to configure Triggers:
Enable (SOUR) or disable (ACC) Bypass: SOURce, ACCeptor.
Query direction.
Path to configure asynchronous Trigger Link:
Select input line (1 to 6).
Query input line.
Select output line (1 to 6).
Query output line.
Path to program arm layer 2:
Loop around control source.
Program scan count (1 to 99999 or INF).
Query scan count.
Program delay (0 to 999999.999 sec)
Query delay.
Select control source: HOLD, IMMediate, TIMer, MANual, BUS, TLINk,
EXTernal.
Query control source.
Set timer interval (0.001 to 999999.999 sec)
Query timer.
Loop around control source.
Path to configure Triggers:
Enable (SOUR) or disable (ACC) Bypass: SOURce, ACCeptor.
Query direction.
Path to configure asynchronous Trigger Link:
Select input line (1 to 6).
Query input line.
Select output line (1 to 6).
Query output line.
4.24.1
4.24.2
4.24.3
4.24.4
4.24.6
4.24.8
4.24.9
4.24.3
4.24.4
4.24.5
4.24.6
4.24.7
4.24.8
4.24.9

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
