2
Getting Started
2-1
2.1 Introduction
This section contains introductory information on operating
your Model 2001 Multimeter. For detailed front panel and
IEEE-488 bus operation, refer to Sections 3 and 4 respective-
ly.
The information in this section is arranged as follows:
2.2 Front and rear panel summary:
Describes the con-
trols and connectors on the front and rear panels, and
the front panel display of the instrument.
2.3 Overview of measurement process:
Provides a brief
description of the measurement process.
2.4 Initial configuration:
Reviews initial configuration
information that should be considered before opera-
tion.
2.5 Front panel operation:
Demonstrates basic front pan-
el operation through the use of simple examples.
2.6 IEEE-488.2 and SCPI basics:
Discusses fundamental
information concerning operation over the IEEE-488
bus, including programming examples.
NOTE
The IEEE-488 bus is also referred to as
GPIB, the general purpose interface bus.
Both terms are used with the Model 2001
and in this manual.
2.2 Front and rear panel summary
2.2.1 Front panel
The front panel controls and connections of the Model 2001
are shown in Figure 2-1. This figure includes important ab-
breviated information that should be reviewed before operat-
ing the instrument. Notice that some of the controls are dual-
function, rocker-action type keys. These include REL/TRIG,
STORE/RECALL, FILTER/MATH, / , INFO/LO-
CAL, CHAN/SCAN, CONFIG/MENU, and EXIT/ENTER.
2.2.2 Rear panel
The rear panel of the Model 2001 is shown in Figure 2-2.
This figure also includes abbreviated information that should
be reviewed before operating the instrument.
The Keithley Applications Department is available at
1-800-348-3735 (U.S. only) to answer any questions
about the Model 2001.
