IEEE-488 Reference
4-172
Bit B11, Buffer Pretriggered (BPT)
Set bit indicates that the trace buffer pretrigger event
has occurred (PTR), or the operations associated with the pretrigger have been completed
(NTR).
Bits B12 through B15
Not used.
Questionable Event Register:
Bits B0 through B3
Not used.
Bit B4, Temperature Summary (Temp)
Set bit indicates that an invalid reference junction
measurement has occurred for thermocouple temperature measurements (PTR), or a subsequent
valid reference junction measurement has occurred (NTR).
Bits B5, B6 and B7
Not used.
Bit B8, Calibration Summary (Cal)
Set bit indicates that an invalid calibration constant was
detected during the power-up sequence (PTR). The instrument will instead use a default calibra-
tion constant. This error will clear after successful calibration of the instrument.
Bits B9 through B13
Not used.
Bit B14, Command Warning (Warn)
Set bit indicates that a Signal Oriented Measurement
Command parameter has been ignored (PTR), or a subsequent Signal Oriented Measurement
Command has executed successfully (NTR).
Note: Whenever a questionable event occurs, the ERR annunciator will turn on. The annunciator
will turn off when the questionable event clears.
RAV
B15 - B12 B10
B9 B8 B7 B6 B5
B4 B3
B2 B1
B0
(2 )
9
(2 )
8
(2 )
7
(2 )
5
(2 )
4
(2 )
3
(2 )
2
(2 )
1
(2 )
0
32
0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Measurement Event Set
0 = Measurement Event Cleared
LL1
2
0/1
Events : BPT = Buffer Pretriggered
BFL = Buffer Full
BHF = Buffer Half Full
BAV = Buffer Available
RAV = Reading Available
HL2 = High Limit 2
LL2 = Low Limit 2
HL1 = High Limit 1
LL1 = Low Limit 1
ROF = Reading Overflow
BFL HL2 HL1 ROF
512 16 4 1
0/1 0/1 0/1 0/1
BHF BAV LL2
256 128 8
0/1 0/1 0/1
BPT
B11
(2 )
11
2048
0/1
igure 4-22
easurement Event Register
