Keithley 2001 User Manual

Front Panel Operation
3-100
Figure 3-42
SCAN key menu structure
Entry for external list ->
SCAN CONFIG EXT SCANNER
Reset scanner; press ENTER to >
< continue.
ENTER CONFIG EXT SCANNER
Set CHAN COUNT to infinite; >
< Press ENTER to continue.
ENTER SELECT TRIG SOURCE
TRIGLINK EXTERNAL TIMER >
< GPIB MANUAL IMMEDIATE
XXXXX CONFIG EXT SCANNER
Set CHAN SPACING to XXXXX. >
< Press ENTER to continue.
ENTER CONFIG EXT SCANNER
Set SCAN LIST for 80 channels >
< Press ENTER to continue.
ENTER CONFIG EXT SCANNER
STEP scanner to first channel >
< Press ENTER to continue.
ENTER
Entry for internal list ->
SCAN SCAN COUNT = 00010
INFO: SCAN COUNT
Use <,>,^,v,ENTER,EXIT, or INFO
Number of scans
ENTER USE SCAN TIMER?
YES NO
YES INTRVL = 000000.000
INFO: TIMER
Use <,>,^,v,ENTER,EXIT, or INFO
For TIMER source, the interval >
< (in seconds) between triggers.
ENTER
NO DATA TO MEMORY?
YES NO
YES XXXXX RDGS TO BUFFER
(Use CONFIG-STORE to
Press ENTER to continue.
change number of readings)
ENTER
NO Press ENTER to begin
XXXX scans of XX channels or >
< press EXIT to abort.
ENTER +000.0000 mVDC CH XX
Storing reading #XXX of XXX
SCAN COMPLETE
Storage complete; press RECALL
SCAN COMPLETE
RECALL-DATA SCAN-AGAIN EXIT
RECALL-DATA +000.000 mVDC
INFO: RECALL BY RDG#
Rdg#+00000 Use <,>,^,v to change reading. >
< Use NEXTDISP to see statistics.
EXIT SCAN COMPLETE
RECALL-DATA SCAN-AGAIN EXIT
SCAN-AGAIN Press ENTER to begin
XXXX scans of XX channels or >
< press EXIT to abort.
EXIT DISABLE EXT SCANNER (For an external list only)
Set CHAN SPACING to MANUAL >
< Press ENTER to continue.

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
