Keithley 2001

Front Panel Operation
3-106
Table 3-42
Main menu structure
Menu item Description
SAVESETUP
SAVE
RESTORE
POWERON
BENCH
GPIB
USER-SETUP-NUMBER
RESET
BENCH
GPIB
Setup menu:
Save setup at a memory location (up to 1, 5, or 10).
Return 2001 to setup stored at a memory location (up to 1, 5, or 10).
Power-on Menu:
Power on to bench default setup conditions.
Power on to GPIB default setup conditions.
Power on to setup stored at a memory location (up to 1, 5, or 10).
Reset Menu:
Return 2001 to bench default setup.
Return 2001 to GPIB default setup.
GPIB
ADDRESSABLE
TALK-ONLY
FEED
AFTER-CALC
BEFORE-CALC
NONE
INTERFACE
IEEE-488
CENTRONICS
INTERVAL
FORMFEED
CONTROL
SET-PAGE-SETUP
ELEMENTS
STATUS
GPIB/Printer Setup menu:
Check/change IEEE-488 bus address (0-30).
GPIB/Printer Talk-only mode menu:
GPIB Output Feed menu:
Specify reading after math operation.
Specify reading before math operation.
Specify no readings.
Select printer interface.
Specify IEEE-488 printer.
Specify Centronics parallel printer.
Specify printing interval (every reading to 1 out of 9999).
Formfeeds menu:
Enable/disable page breaks.
Set number line between form feeds (1-255).
Select GPIB data elements (reading, units, reading number, channel number, timestamp,
status).
Display IEEE-488 bus status byte.
CALIBRATION
COMPREHENSIVE
AC-ONLY-CAL
CALIBRATION-DATES
Calibration menu:
Perform DC and AC calibration.
Perform AC calibration only (open-circuit).
Check/change calibration date.
TEST
BUILT-IN-TEST
AUTOMATIC
MANUAL
DIAGNOSTICS
FRONT-PANEL-TESTS
KEYS
DISPLAY-PATTERNS
Self-test menu:
Test analog and digital boards.
Run all tests automatically.
Select tests to run.
Factory diagnostic tests.
Test display board.
Verify operation of front panel keys.
Verify operation of display.
