Keithley 2001

SCPI Command Subsystems
D-5
Table D-4
FORMat command summary
Command Description
:FORMat
[:DATA] <type>[,<length>]
[:DATA]?
:ELEMents <item list>
:ELEMents?
:BORDer <name>
:BORDer?
:EXPonent <name>
:EXPonent?
Select data format: ASCii, REAL,32, REAL,64, SREal or DREal.
Query data format.
Specify data elements: READing, CHANnel, RNUMber, UNITs, TIMEstamp
and STATus.
Query data elements.
Select binary byte order: NORMal, SWAPped.
Query byte order.
Set exponent format: NORMal, HPRecision.
Query exponent format.
Table D-5
OUTPut command summary
Command Description
:OUTPut
:TTL[1]
:LSENse <name>
:LSENse?
:TTL2
:LSENse <name>
:LSENse?
:TTL3
:LSENse <name>
:LSENse?
:TTL4
:LSENse <name>
:LSENse?
Path to set polarity of digital output line 1:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 1.
Path to set polarity of digital output line 2:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 2.
Path to set polarity of digital output line 3:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 3.
Path to set polarity of digital output line 4:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 4.
