SCPI Command Subsystems
D-3
:CALCulate3
:LOWer
[:DATA] <n>
[:DATA]?
:SOURce <NRf>
:SOURce?
:STATe <b>
:STATe?
:FAIL?
:CLEAR
[:IMMediate]
:AUTO <b>
:AUTO?
:PASS
:SOURce <NRf>
:CLIMits
:FAIL?
:BSTRobe
:STATe <b>
:STATe?
:IMMediate
Path to configure lower limit:
Specify lower limit (-9.99e35 to +9.999999e35).
Query lower limit.
Specify digital output (0 to 15).
Query source (digital output value).
Enable (1 or ON) or disable (0 or OFF) limit test.
Query state of limit test.
Query test result (1=pass, 0=fail).
Path to clear failed test:
Clear failed test indication.
Enable (1 or ON) or disable (0 or OFF) auto clear.
Query auto clear.
Path to define “pass” digital output pattern.
Specify digital output (0 to 15).
Command path for composite limits:
Query composite result of LIMIT 1 and LIMIT 2 tests (1=pass, 0=fail).
Path to control limit binning strobe:
Enable (1 or ON) or disable (0 or OFF) strobe.
Query state of binning strobe.
Re-perform limit tests.
Table D-2
CALibrate command summary
Command Description
:CALibration
:PROTected
:LOCK
:SWITch?
:SAVE
:DATA?
:DATE “<string>”
:DATE?
:NDUE “<string>”
:NDUE?
:LLEVel
:SWITch?
:STEP <Step #>
1
2
3
4
5
6
7
8
9
Calibration root command.
All commands in this subsystem are protected by the CAL switch.
Lock out calibration (opposite of enabling cal with CAL switch).
Request comprehensive CAL switch state.
(0 = locked; 1 = unlocked)
Save cal constants to EEPROM.
Download cal constants from 2001.
Send cal date to 2001.
Request cal date from 2001.
Send next due cal date to 2001.
Request next due cal date from 2001.
Low-level calibration subsystem.
Request low-level CAL switch state. (0 = locked; 1 = unlocked)
20V AC at 1kHz step.
20V AC at 30kHz step.
200V AC at 1kHz step.
200V AC at 30kHz step.
1.5V AC at 1kHz step.
0.2V AC at 1kHz step.
5mV AC at 100kHz step.
0.5mV AC at 1kHz step.
+2V DC step.
Table D-1 (cont.)
Calculate command summary
Command Description
