Front Panel Operation
3-23
Figure 3-9 (continued)
DC voltage multifunction multiple displays
DCV
RANGE = Set by DCV range (auto or Þxed).
Autoranges independently of other functions.
REL = Operates normally.
SPEED = Set by DCV speed.
FILTER = Set by DCV Þlter.
RESOLUTION = Set by DCV resolution.
Pos-Pk
RANGE = Follows the DCV range.
REL = No effect.
SPEED = Fixed at 100msec.
Peak window has no effect.
FILTER = Unaffected by DCV and ACV filters.
RESOLUTION = Fixed at 3.5 digits.
UNITS = Fixed on volts.
COUPLING = Fixed on AC+DC coupling.
NOTE: The peak detector captures the maximum
value of the input signal.
+000.0000 mVDC
Pos-Pk=+000.0mV Highest=+000.0mV
Highest
REL = No effect.
RESOLUTION = Fixed at 3.5 digits.
UNITS = Fixed on volts.
NOTE: The highest value is reset by pressing the
DCV key, or changing function (i.e., leaving this
display).
B. DC voltage and positive peak spikes functions
