3-8 Keysight B1505A Configuration and Connection Guide
N1265A Connection Guide
Input Connection
Table 3-4 To Connect between B1505A and N1265A for using UHVU (N1268A)
WARNING Connect a wire from an electrical ground (safety ground) to the earth terminal.
B1505A terminals Required cables
N1268A terminals
1
1. To configure UHVU, the N1268A ultra high voltage expander is required.
Interlock
16493J-001 Interlock cable, 1.5 m, 1 ea.
Interlock Input
MCSMU Force 16494A-001 Triaxial cable, 1.5 m, 1 ea.
I Control
Force
Sense 16494A-001 Triaxial cable, 1.5 m, 1 ea. Sense
MCSMU
2
2. HCSMU is substitutable. Then use 16493S HCSMU cable, N1254A-103 adapter for Force, and
N1254A-517 adapter for Sense.
Force 16494A-001 Triaxial cable, 1.5 m, 1 ea.
V Control
Force
Sense 16494A-001 Triaxial cable, 1.5 m, 1 ea. Sense
N1268A terminals Required cables N1265A terminals
Interlock Output
16493J-001 Interlock cable, 1.5 m, 1 ea.
Interlock
Output High UHV(plug)-UHV(plug) cable, 1.5 m, 1 ea. (part of 16493V-001)
UHV
High
Low SHV(plug)-SHV(plug) cable, 1.5 m, 1 ea. (part of 16493V-001) Low
Digital I/O
1
1. If the N1266A expander is used, connect the 16493G-001 cable from the N1266A Digital I/O Output.
16493G-001 Digital I/O connection cable, 1.5 m, 1 ea. Digital I/O Output
LINE Power cable, 1 ea., for connecting to power line
(earth) Wire, 1 ea., for earthing
To Next Page
