Keysight Technologies B1505A Configuration Guide

Keysight B1505A Configuration and Connection Guide 1-61
Configuration Guide
Retrofit Products for B1505A
Retrofit Products for B1505A
The Keysight B1505A has 10 slots so that users can install appropriate modules into
B1505A mainframe. The retrofit module product is available to add more modules into
existing B1505A mainframe. These modules have to be installed in Keysight Technologies
service center to meet the specifications.
The following table lists the module products and the available accessories.
Table 1-28 Module products and available accessories
Model/
Option
Description Note
B1505AU Upgrade kit for B1505A
Software license to use advanced functions
B1505AU-SWS EasyEXPERT Extension support and subscription • B1505A users who have not
purchased a B1505A-SWS
have to update EasyEXPERT
software to version 5.5 or
later.
• The B1505AU-SWS includes
15 licenses which can be
used for both EasyEXPERT
and Desktop EasyEXPERT.
Measurement module
B1505AU-010 High Power Source/Monitor Unit Module (B1510A) Modules are NOT furnished with
any cables. Order the required
cables and accessories separately.
B1505AU-011 Medium Power Source/Monitor Unit Module
(B1511B)
B1505AU-012 High Current Source Monitor Unit Module (B1512A)
B1505AU-013 High Voltage Source Monitor Unit (B1513C)
B1505AU-014 Medium Current Source Monitor Unit (B1514A)
B1505AU-020 Multi Frequency Capacitance Measurement Unit
Module (B1520A)
B1510A HPSMU, B1511A/B MPSMU and B1514A MCSMU cables
16494A-001 1.5m length triaxial cable
16494A-002 3 m length triaxial cable
16494A-003 80 cm length triaxial cable
16494A-004 40 cm length triaxial cable
16494A-005 4 m length triaxial cable
