1-62 Keysight B1505A Configuration and Connection Guide
Configuration Guide
Retrofit Products for B1505A
NOTE For customers, module upgrades to existing B1505A systems must be carried out at an
Keysight Technologies service center. In order to ensure system specifications the new
modules need to be installed and the complete unit calibrated. Contact your nearest
Keysight Technologies office to arrange the installation and calibration of new B1505A
modules.
NOTE For Keysight field team, installation fee (R-51U-501 or R1286A-HU) will be
automatically added to the B1505AU when making a quotation with Keysight order
configuration tool.
NOTE E5288A ASU (Atto Sense and Switch Unit) is not supported by the B1505A.
16493K-001 1.5 m length Kelvin triaxial cable
16493K-002 3 m length Kelvin triaxial cable
B1512A HCSMU cables and adapters
16493S-001 1.5 m length
16493S-002 3 m length
16493S-010
1
HCSMU Kelvin adapter
16493S-011
1
HCSMU non-Kelvin adapter
16493S-020
1
Dual HCSMU combination adapter, for 40 A
measurement, when connecting to wafer prober
directly without N1258A selector
16493S-021
1
Dual HCSMU combination adapter, for 40 A
measurement, when being used with N1259A test
fixture, N1258A module selector, or 16493S-010/011
HCSMU adapter
The 16493S-021 is furnished
with one 30cm Triaxial cable and
one 30 cm High current coaxial
cable for output connection.
B1513A/B/C HVSMU cables
16493T-001 1.5 m length
16493T-002 3 m length
B1520A CMU cables
N1300A-001 1.5 m length
N1300A-002 3 m length
1. Do not connect or put any conductor on the HCSMU Low Force and Low Sense terminals, outer con-
ductor of the coaxial connectors. Connecting or putting conductor of circuit common, chassis ground,
or any potential on causes the measurement error.
Model/
Option
Description Note
