Keysight Technologies B1505A Configuration Guide

Keysight B1505A Configuration and Connection Guide 1-7
Configuration Guide
B1505A Modules and Mainframe Options
B1505A Modules and Mainframe Options
The B1505A can contain several combinations of modules; up to four dual-slot HPSMU
modules, up to ten MPSMU, up to two dual-slot HCSMU modules, up to five dual-slot
HVSMU, up to six MCSMU and one single-slot MFCMU.
• Select the modules to be installed in the B1505A mainframe
See Table 1-4 for the plug-in modules supported by the B1505A.
• Specify cable length, 1.5 m or 3 m
See Table 1-5 for the options available for the B1505A.
• Select power line frequency, paper manual, rack mount kit, service options, and so on
See Table 1-5 for the options available for the B1505A.
Table 1-4 Plug-in Modules Supported by B1505A
Module type Description
Slots
occupied
Maximum number of
modules installed in
B1505A
HPSMU
1
1. Total number of installed HPSMU and HCSMU modules cannot exceed 4.
High Power Source/Monitor Unit module 2 4
MPSMU Medium Power Source/Monitor Unit
module
110
HCSMU
1, 2
2. Dual HCSMU (DHCSMU) configuration is available if two HCSMU modules are installed in one
mainframe and connected to the 16493S-020 Dual HCSMU Kelvin adapter or the 16493S-021 Dual
HCSMU adapter. This configuration expands the maximum current up to ± 40 A (pulse), ± 2 A (DC).
High Current Source/Monitor Unit
module
22
HVSMU
3
3. For B1513C only. Multiple B1513A/B1513B HVSMU modules cannot be installed in one mainframe.
High Voltage Source/Monitor Unit
module
25
MCSMU Medium Current Source Monitor Unit
module
16
MFCMU Multi Frequency Capacitance
Measurement Unit module
11
GNDU
4
4. GNDU has been installed in the mainframe. You do not need to count for the number of slots occupied.
Ground Unit --
