1-40 Keysight B1505A Configuration and Connection Guide
Configuration Guide
Pre-configured Power Device Analyzer/Curve Tracer (B1505A with Modules/Fixture)
Pre-configured Power Device Analyzer/Curve Tracer
(B1505A with Modules/Fixture)
The Keysight B1505AP Pre-configured packages include all necessary modules, cables
and accessories.
Table 1-17 B1505AP Pre-configured package
Table 1-18 B1505AP-H20 3 kV / 20 A / Fixture Package
Product Number Description
B1505AP Pre-configured Power Device Analyzer/Curve Tracer (B1505A w/
modules/fixture)
Option Max V Max I C-V Note
H20 3 kV 20 A 3 kV / 20 A / Fixture Pack
H21 3 kV 20 A Yes 3 kV / 20 A / C-V / Fixture Pack
H50 3 kV 500 A 3 kV / 500 A / Fixture Pack
H51 3 kV 500 A Yes 3 kV / 500 A / C-V / Fixture Pack
H70 3 kV 1500 A 3 kV / 1500 A / Fixture Pack
H71 3 kV 1500 A Yes 3 kV / 1500 A / C-V / Fixture Pack
U50 10 kV 500 A 10 kV / 500 A / Fixture Pack
U70 10 kV 1500 A 10 kV / 1500 A / Fixture Pack
Description Qty Note
B1505A 1 Power Device Analyzer / Curve Tracer Mainframe
• Include 16493J-001 Interlock cable (1.5 m), 16493L-001 GNDU cable (1.5
m), 16444A-001 Keyboard, 16444A-002 Mouse, 16444A-003 Stylus pen.
B1512A-FG 1 High Current Source Monitor Unit Module
• Include 16493S-001 HCSMU cable (1.5 m) 1ea and 16493S-010 Kelvin
adapter.
B1513C-FG 1 High Voltage Source Monitor Unit
• Include 16493T-001 HVSMU cable (1.5 m).
B1514A-FG 1 Medium Current Source Monitor Unit
• Include 16494A-001 Triaxial cable (1.5 m) 2ea.
N1259A 1 Test Fixture for Power Device
To Next Page
