Keysight B1505A Configuration and Connection Guide 5-15
Connection Guide for Wafer Prober and Your Own Test Fixture
To Connect High Voltage R-Box
Table 5-9 To Connect N1262A Output
Voltage drop caused by the R-box must be subtracted from the measurement result as
following.
Vdut = Vout - Rs Imeas
where, Vdut: Voltage after correction, Vout: Source output voltage, Rs: Resistance of the
series resistor, and Imeas: Measurement current
To Use Universal R-Box
To install your desired resistor, see the following simple instruction.
•tRequired parts:
wire, adequate rating, length, and quantity
your desired resistor, adequate rating
hexlobe (torx type) screwdriver T-10
label, for noting resistance value
• Instruction:
1. Remove the cover of the universal R-box.
2. Solder the resistor and wire as shown below.
To prevent discharge and any accident, make enough space between the resistor
leads and the shield or chassis. For example, make space of about 1 mm from the
leads for maximum 200 V output, 6 mm for 3000 V, and 32 mm for 10 kV.
Case 1: N1262A-020/021, see Figure 5-1.
• Connect a wire between a terminal and the center conductor of its near
connector.
• Connect a wire between the other terminal and the center conductor of the other
connector.
• Connect the resistor between the terminals.
Options Required cables/Description Connect to
N1262A-001 Coaxial cable with SHV(plug) connector. DUT terminal
(ex: drain)
N1262A-002 Coaxial cable with SHV(plug) connector.
N1262A-010 Triaxial cable with Triaxial(m) connector. DUT terminal
(ex: gate)
N1262A-011 Coaxial cable with SHV(plug) connector.
N1262A-020 Triaxial cable with Triaxial(m) connector.
N1262A-021 Coaxial cable with SHV(plug) connector.
N1262A-023 Coaxial cable with UHV(plug) connector.
