Keysight B1505A Configuration and Connection Guide 1-9
Configuration Guide
B1505A Modules and Mainframe Options
Module type and locations
Module locations when the B1505A is shipped from the factory are shown in Table 1-6 on
page 1-10. This table shows the relative locations by the module types.
If HPSMUs are installed, the HPSMUs must be installed in the slots from the slot number
1. And if HPSMU and MPSMU and MFCMU are not installed and MCSMUs are installed,
the MCSMUs must be installed in the slot number 1. Then the same type of modules must
be installed in the contiguous slots.
For example, if the module configuration is one MFCMU, three MCSMUs, one HCSMU
and one HVSMU, the B1505A will be shipped with the MFCMU of the slot 1, the
MCSMUs of the slot 2 to 4, the HCSMU of the slot 5 to 6, the HVSMU of the slot 7 to 8,
and the blank panels of the slot 9 to 10.
Description
Model/
Option
Note
Specify the power line frequency (mandatory)
50Hz line frequency 050
60Hz line frequency 060
Select calibration options (optional)
ANSI Z540 compliant calibration A6J
Commercial calibration certificate with test
data
UK6
Specify the language of the paper manuals if you need
Paper manual set, English ABA • Printed manuals are optional. Order this
option to get the paper manuals. It contains
B1505A user guide, quick start guide, and
self-paced training manual, EasyEXPERT
user guide and self-paced training manual,
and B1500 series programming guide.
Paper manual set, Japanese ABJ
Select rack mount kit (optional)
Rack mount kit 1CM
