Keysight Technologies B1505A Configuration Guide

1-48 Keysight B1505A Configuration and Connection Guide
Configuration Guide
Accessories for Wafer Prober and Your Own Test Fixture
Accessories for Wafer Prober and Your Own Test
Fixture
Table 1-26 lists the accessories available for wafer probers or your own test fixtures. Select
the required accessories.
Figure 1-4 Connection to probers
Figure 1-5 Connection between the N1265A Ultra High Current Expander / Fixture and Prober
with the N1254A-524 Ultra High Current Prober System
Condition Gate Drain Source
Other bias
500 A
N1265A UHC Expander / Fixture
+ N1254A-524 Ultra High Current Prober
System Cable
MCSMU*<=30A with Module
Selector
MCSMU* +
R-box
N1258A Module Selector
<=40A without Module
Selector
Direct Direct
Condition Gate Drain Source
Other bias
10 kV** N1269A UHV direct N1269A
MCSMU +
N1269A
* We recommend B1514A MCSMU for a Gate SMU and other bias SMUs.
** We should manually change cabling for a 10 kV measurement
