1-64 Keysight B1505A Configuration and Connection Guide
Configuration Guide
Conversion Kit from B1500A to B1505A
Conversion Kit from B1500A to B1505A
The following table lists the requirements and the available accessories for remodelling the
B1500A to the B1505A.
Table 1-29 Required and Available Accessories for Remodelling B1500A to B1505A
NOTE For customers, Keysight Technologies service center is responsible for remodelling and
module installation. Contact Keysight Technologies to get a quotation.
NOTE For Keysight field team, installation fee (R-51U-501 or R1286A-HU) will be
automatically added to the B1505AU when making a quotation with Keysight order
configuration tool.
NOTE The instrument firmware and software will be updated to the latest version at the service
center. So make a back up of data saved in the built-in HDD by yourself before sending the
instrument to the service center.
NOTE The 16442A/16442B test fixture supports up to 200 V / 1A. So use the N1259A or the
N1265A, which are designed for supporting the B1505A. See "N1259A Test Fixture for
Power Device" or "N1265A Ultra High Current Expander/Fixture".
NOTE B1517A HRSMU (high resolution SMU), E5288A ASU (Atto Sense and Switch Unit),
B1530A WGFMU (Waveform Generator / Fast Measurement Unit), and B1525A SPGU
(High Voltage Semiconductor Pulse Generator Unit) are not supported by the B1505A.
Model/
Option
Description Note
B1505AU-001 Conversion kit from B1500A to
B1505A
The B1505AU-001 is NOT furnished with any
cables. It doesn’t include any modules. Select
modules or accessories separately. Please refer to
"Retrofit Products for B1505A" on page 1-61.
To Next Page
