1-8 Keysight B1505A Configuration and Connection Guide
Configuration Guide
B1505A Modules and Mainframe Options
Table 1-5 Mainframe Options
Description
Model/
Option
Note
Mainframe
Power Device Analyzer/Curve Tracer B1505A • See Table 1-3 on page 1-6 for furnished
accessories
Select modules (optional)
High Power Source/Monitor Unit module
(HPSMU), 200 V/1 A
B1510A-FG • Furnished with two triaxial cables
(16494A). Cable length 1.5 m or 3.0 m is
specified by 015 or 030.
• Up to four modules can be installed.
• The total number of installed HPSMU and
HCSMU modules cannot exceed 4.
Medium Power Source/Monitor Unit module
(MPSMU）, 100 V/100 mA
B1511B-FG • Furnished with two triaxial cables
(16494A). Cable length 1.5 m or 3.0 m is
specified by 015 or 030.
• Up to ten modules can be installed.
High Current Source/Monitor Unit module
(HCSMU), 20 A at 20 V
B1512A-FG • Furnished with one pair of high current
cables (16493S) and Kelvin adapter
(16493S-010). Cable length 1.5 m or 3.0 m
is specified by 015 or 030.
• Up to two modules can be installed.
• The total number of installed HPSMU and
HCSMU modules cannot exceed 4.
High Voltage Source/Monitor Unit module
(HVSMU), 3000 V at 4 mA
B1513C-FG • Furnished with one HVSMU cable
(16493T). Cable length 1.5 m or 3.0 m is
specified by option 015 or 030.
• Up to five modules can be installed.
Medium Current Source Monitor Unit
module (MCSMU), 1 A at 30 V
B1514A-FG • Furnished with two triaxial cables
(16494A). Cable length 1.5 m or 3.0 m is
specified by 015 or 030.
• Up to six modules can be installed.
Multi Frequency Capacitance Measurement
Unit module (MFCMU)
B1520A-FG • Furnished with one CMU cable (N1300A).
Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
• Up to one modules can be installed.
Specify the cable length (mandatory)
1.5m cable 015 • Same cable length is applied to all
furnished cables.
3.0m cable 030
