5-12 Keysight B1505A Configuration and Connection Guide
Connection Guide for Wafer Prober and Your Own Test Fixture
Connection Overview
N1274A On-wafer gate charge measurement
adapter/selector for 20 A/3 kV
For on-wafer gate charge measurements
using the HCSMU (max. 20 A) and
HVSMU (max. 3 kV).
N1275A On-Wafer gate charge measurement adapter for
N1265A
For on-wafer gate charge measurements
with the UHCU (max. 500 A) and
HVSMU (max. 3 kV).
N1254A-103 BNC(f)-Triaxial(m) adapter, triaxial shield open For using HCSMU instead of MCSMU
N1254A-517 Triax(f)-Triax(m) adapter, shield separated
N1254A-104 BNC(m)-Triaxial(f) adapter, triaxial shield open For using MCSMU instead of HCSMU
N1254A-106 BNC(f)-Triaxial(m) adapter, triaxial guard open For changing N1262A-010 triax to BNC
N1254A-402 Interlock micro switch For making interlock circuit. See "To
Install an Interlock Circuit" on page
5-47.
1252-1419 Interlock connector (6 pin, female)
1450-0641 LED (V
F
2.1 V @ I
F
= 10 mA)
N1254A-500 HV(jack) connector, panel mount, for soldering For connecting HVSMU or accessory to
your DUT interface.
N1254A-501 HV(jack)-HV(jack) adapter, panel mount
N1254A-502 HV(plug) connector, panel mount, for soldering
N1254A-503 BNC(m) to no connector coaxial cable, 1.5 m For connecting accessory to your DUT
interface.
N1254A-504 HV(jack) to no connector coaxial cable, 1.5 m
N1254A-505 HV(plug) to no connector triaxial cable, 1.5 m
N1254A-506 HV(plug) to no connector coaxial cable, 1.5 m
N1254A-507 HV(plug)-HV(plug) coaxial cable, 1.5 m
N1254A-516 BNC(f)-(f)-(f) adapter
N1254A-518 SHV(plug)-SHV(plug) coaxial cable, 1.5 m For connecting N1260A to N1265A.
N1254A-520 UHV(plug) to no connector cable, 1 m and
SHV(plug) to no connector cable, 1 m
For connecting UHVU to your DUT
interface.
N1254A-521 UHV(jack)-UHV(jack) adapter and
SHV(jack)-SHV(jack) adapter
N1254A-523 Banana to no connector wire, 1 m, 2 ea. For connecting UHCU to probe station.
N1254A-524 System cable for prober, 1.8 m
