5-24 Keysight B1505A Configuration and Connection Guide
Connection Guide for Wafer Prober and Your Own Test Fixture
To Connect Protection Adapter
Table 5-17 To Connect N1261A Output
Options Required cables/Description Connect to
N1261A-001
Force Triaxial cable with Triaxial(m) connector. DUT terminal
(ex: gate)
or
Prober chuck
Sense Triaxial cable with Triaxial(m) connector.
N1261A-003
Force Triaxial cable with HV(plug) connector. N1254A-505 can be used.
Also 16493T-001 and N1254A-500 can be used.
Sense Triaxial cable with HV(plug) connector. N1254A-505 can be used.
Also 16493T-001 and N1254A-500 can be used.
N1261A-002
1
1. For connecting HCSMU adapter, see "To Connect HCSMU Adapter" on page 5-17.
Force Coaxial cable with BNC(m) connector. N1254A-503 can be used. DUT terminal
(ex: source)
Non-Kelvin
connection is
not allowed.
Sense Coaxial cable with BNC(m) connector. N1254A-503 can be used.
N1261A-004
Force Coaxial cable with SHV(plug) connector.
Sense Coaxial cable with SHV(plug) connector.
N1261A
Opt 001
HPSM U Protection Adapter
Force
Sense
From
HPSMU
Output
Guard
Sense/
Force
Circuit
Common
!
Force
㼼200V max
䞉䞉䞉䞉
Sense
㼼200V max
䞉䞉䞉䞉
Agilent
Inp ut
Peak 㼼3kV=max
N1261A
Opt 001
HPSM U Protection Adapter
Force
Sense
From
HPSMU
Output
Guard
Sense/
Force
Circuit
Common
!
Guard
Sense/
Force
Circuit
Common
!!
Force
㼼200V max
䞉䞉䞉䞉
Force
㼼200V max
䞉䞉䞉䞉
㼼200V max
䞉䞉䞉䞉䞉䞉䞉䞉
Sense
㼼200V max
䞉䞉䞉䞉
Sense
㼼200V max
䞉䞉䞉䞉
㼼200V max
䞉䞉䞉䞉䞉䞉䞉䞉
Agilent
Inp ut
Peak 㼼3kV=max
N1261A
Opt 002
GNDU Protection Adapter
From GNDU
Output
Force
Sense
Agilent
Force
Sense
Circuit
Common
Sense/
Force
Circuit
Common
㼼40 V m ax
䞉䞉䞉
Inp ut
Peak 3kV=max
N1261A
Opt 002
GNDU Protection Adapter
From GNDU
Output
Force
Sense
Agilent
Force
Sense
Circuit
Common
Force
Sense
Circuit
Common
Sense/
Force
Circuit
Common
Sense/
Force
Circuit
Common
㼼40 V m ax
䞉䞉䞉
㼼40 V m ax
䞉䞉䞉䞉䞉䞉
Inp ut
Peak 3kV=max
