Keysight B1505A Configuration and Connection Guide 5-33
Connection Guide for Wafer Prober and Your Own Test Fixture
To Connect HVSMU/HCSMU Fast Switch
Table 5-23 To Connect N1267A Input
Table 5-24 To Connect N1267A Output
CAUTION The GNDU can sink current of up to 4.2 A. Use 16493L GNDU cable to connect the
GNDU to the N1267A.
Do not use normal triaxial cable (16494A) because the maximum current rating of the
cable is 1 A.
CAUTION Never connect the HVSMU Force and Guard terminals to any output, including circuit
common, chassis ground, or any other measurement resource such as SMU. Connecting
other measurement resource may damage the connected one.
NOTE Do not connect or put any conductor on the HCSMU Low Force and Low Sense terminals,
outer conductor of the coaxial connectors. Connecting or putting conductor of circuit
common, chassis ground, or any potential on causes the measurement error.
B1505A terminals Required cables N1267A terminals
HCSMU
Force 16493S HCSMU cable, 3 m or 1.5 m, 1 ea.
HCSMU
Force
Sense Sense
HVSMU
Force 16493T HVSMU cable, 3 m or 1.5 m
HVSMU
GNDU
16493L GNDU cable, 3 m or 1.5 m
GNDU
MCSMU Force 16494A Triaxial cable, 3 m or 1.5 m MCSMU Force
Sense 16494A Triaxial cable, 3 m or 1.5 m Sense
N1267A
terminals
Required cables/Description Connect to
Low Force Coaxial cable with BNC(m) connector. N1254A-503 can be used. DUT low terminal
(ex: source)
High Force Coaxial cable with HV(plug) connector. N1254A-506 can be used.
Use coaxial cable to minimize affect of inductance.
DUT high terminal
(ex: drain)
To Next Page
