6-8 Keysight B1505A Configuration and Connection Guide

Accessory Dimensions

Figure 6-9 N1258A Module Selector, in mm

108.2

(17.8)

87.2

186.2

(17.8)

357.4

(408)

M3 5 ea, < 10 mm

330.2

372.4
