Keysight B1505A Configuration and Connection Guide 7-11
Connection and Ordering Examples
Package Device Measurement Configuration Examples
NOTE This configuration is equivalent to the B1505AP-H51 3 kV / 500 A / C-V / Fixture Pack or
B1505AP-H71 3 kV / 1500 A / C-V / Fixture Pack configuration.
N1265A-015 1 1500 A Current Option
(This option needs to be ordered only when 1500 A capability is required)
N1254A 1 Accessories for instruments and fixtures
N1254A-508 4 Banana to Banana Cable 250 mm (red, 1ea)
N1254A-509 4 Banana to Banana Cable 250 mm (black, 1ea)
N1254A-510 3 Dolphin Clip 2ea (red and black)
N1254A-512 2 SHV Cable 250 mm
N1254A-513 2 SHV Jack to Banana Adapter
N1254A-518 2 SHV Cable 1.5 m
N1262A 1 R-box for B1505A
N1262A-036 1 50 Ohm Termination Adapter
1251-2277 1 Banana to BNC Adapter
Model/Option Quantity Description
