Keysight Technologies B1505A Configuration Guide

7-24 Keysight B1505A Configuration and Connection Guide
Connection and Ordering Examples
Package Device Measurement Configuration Examples
16493L-001 1 Ground Unit Cable (Triaxial, 1.5 m)
16493V 1 10 kV Ultra High Voltage Cable
16493V-001 1 10 kV Ultra High Voltage Cable (1.5 m)
N1265A 1 Ultra High Current Expander/Fixture
N1265A-001 1 Ultra High Current Expander/Fixture
N1265A-010 1 500 A Ultra High Current 3-pin Inline Package Socket Module
N1264A-040 1 10 kV Ultra High Voltage Gate Protection Adapter
N1266A 1 High Voltage Source Monitor Unit Current Expander
N1268A 1 Ultra High Voltage Expander
N1268-STD 1 Ultra High Voltage Expander
N1254A 1 Accessories for instruments and fixtures
N1254A-508 4 Banana to Banana Cable 250 mm (red, 1ea)
N1254A-509 4 Banana to Banana Cable 250 mm (black, 1ea)
N1254A-510 3 Dolphin clip adapter, black 1 ea. and red 1 ea.
N1254A-520 1 10 kV Ultra High Voltage Open End Cable, 1 m
N1262A 1 R-box for B1505A
N1262A-036 1 50 Ohm Termination Adapter
1251-2277 1 Banana to BNC Adapter
Model/Option Quantity Description
