Keysight B1505A Configuration and Connection Guide 7-77
Connection and Ordering Examples
Upgrading from existing B1505A
16494A-001 or
002
2 Triaxial Cable (1.5 m or 3.0 m)
(Two Triaxial cables which existing B1510A is furnished with can be
re-used)
N1265A 1 Ultra High Current Expander / Fixture
N1265A-001 1 Ultra High Current Expander / Fixture
N1265A-010 1 500 A Ultra High Current 3-pin Inline Package Socket Module
N1265A-015 1 1500 A Current Option
N1260A 1 High Voltage Bias-Tee
N1260A-STD 1 High Voltage Bias-Tee
N1254A 1 Accessories for instruments and fixtures
N1254A-512 2 SHV Cable 250 mm
N1254A-513 2 SHV Jack to Banana Adapter
N1254A-518 2 SHV Cable 1.5 m
N1262A 1 R-box for B1505A
N1262A-036 1 50 Ohm Termination Adapter
1251-2277 1 Adapter-BNA BNC Jack Black
Model/Option Quantity Description
