1-46 Keysight B1505A Configuration and Connection Guide
Configuration Guide
Pre-configured Power Device Analyzer/Curve Tracer (B1505A with Modules/Fixture)
Table 1-25 B1505AP-U70 10 kV / 500 A / Fixture Package
N1254A-510 3 Dolphin Clip 2 ea. (red and black)
N1254A-520 1 10 kV Ultra High Voltage Open End Cable, 1m (pair)
N1254A-522 1 1500 A Ultra High Current Banana to Banana Cable, 2 ea
Description Qty Note
B1505A 1 Power Device Analyzer / Curve Tracer Mainframe
• Include 16493J-001 Interlock cable (1.5 m), 16493L-001 GNDU cable (1.5
m), 16444A-001 Keyboard, 16444A-002 Mouse, 16444A-003 Stylus pen.
B1514A-FG 5 Medium Current Source Monitor Unit
• Include 16494A-001 Triaxial cable (1.5 m) 2ea.
N1265A 1 Ultra High Current Expander / Fixture
N1265A-001 1 Ultra High Current Expander / Fixture
• Include 16493G-001 Control cable (1.5 m) and a Blanck silicon plate.
N1265A-010 1 500 A Ultra High Current 3-pin Inline Package Socket Module
• Include N1254A-522 1500 A Ultra High Current Banana to Banana Cable
(yellow, 2ea), N1254A-508 Banana to Banana Cable, 250 mm (red, 1ea),
N1254A-509 Banana to Banana Cable, 250 mm (black, 1ea), N1265-61751
Test Lead 180mm (red, 1ea) and N1265A-61752 Test Lead 180mm (black,
1ea).
N1265A-015 1 1500 A Current Option
N1265A-040 1 10 kV Ultra High Voltage Gate Protection Adapter
N1268A 1 Ultra High Voltage Expander
N1268A-STD 1 Ultra High Voltage Expander
• Include 16493G-001 Control cable (1.5 m), 16493J-001 Interlock cable
(1.5m).
16493V-001 1 10 kV Ultra High Voltage Cable, 1.5 m
• Include one UHV cable (red) and one SHV cable (black).
N1254A 1 Accessories for instruments and fixtures
N1254A-508 4 Banana to Banana Cable 250 mm (red, 1ea)
N1254A-509 4 Banana to Banana Cable 250 mm (black, 1ea)
N1254A-510 3 Dolphin Clip 2 ea. (red and black)
N1254A-520 1 10 kV Ultra High Voltage Open End Cable, 1m (pair)
N1254A-522 1 1500 A Ultra High Current Banana to Banana Cable, 2 ea
Description Qty Note
