N9030B PXA Signal Analyzer Service Gu
ide
441
Assembly Replacement Procedur
es
RF Ar
ea (Options 503
, 508, 513, 526)
Figur
e 16-8
Attenuators Remov
al
T
ab
le 16-3
Item
Keysight Pa
rt Numb
er
W2
N90
20-20100
W3
N90
20-20023
W4
N90
20-20025
W6
N90
20-20024
440
442
