Keysight Technologies N9030B

468 N9030B PXA Signal Analyzer Service Guide
Assembly Replacement Procedures
RF Area (Options 503, 508, 513, 526)
10.Refer to Figure 16-37. Install rigid cable W52 (N9020-20146) between top
switch port 4 and Low Band Switch Assembly connector that is closest to
the inner chassis. Torque to 10 inch-lbs.
Figure 16-37 W52 Installation
Table 16-7
Item Keysight Part Number
W52 N9020-20146
